DSO138 Oscilloscope enclosure

The DSO138 Oscilloscope Enclosure is a protective case designed specifically for the DSO138 Digital Oscilloscope kit. This enclosure provides a durable and stylish housing, safeguarding the oscilloscope from dust, debris, and potential damage while maintaining easy access to all controls and connections. It enhances the overall usability and portability of the DSO138 oscilloscope, making it more convenient for fieldwork and everyday use.

Key Features:

• Compatibility: Designed specifically for the DSO138 Digital Oscilloscope
• Material: High-quality acrylic
• Protection: Shields the oscilloscope from dust, debris, and physical impact
• Access: Precise cutouts for display, controls, and connections
• Assembly: Easy to assemble with included hardware
• Visibility: Transparent design allows clear view of the oscilloscope display and status LEDs

Technical Specifications:

• Material: Acrylic
• Dimensions: Compatible with DSO138 board dimensions (117mm x 76mm x 15mm)
• Weight: Lightweight design for enhanced portability
• Color: Transparent with protective film (remove before use)
• Included Components: Acrylic panels, screws, nuts, standoffs, and assembly instructions

Applications:

• Protection: Provides robust protection for the DSO138 oscilloscope, extending its lifespan.
• Portability: Enhances portability for fieldwork and on-the-go diagnostics.
• Aesthetics: Improves the visual appeal of the oscilloscope setup.
• Education: Ideal for educational environments where equipment is frequently handled.

Datasheet:
For detailed assembly instructions, refer to the DSO138 Oscilloscope Enclosure Assembly Guide.
