UNI-T UT136B+ AC DC Multimeter

UNI-T UT136B+ AC DC Multimeter

40,500.00

In stock

SKU: 2397 Category:

The new generation of UT136+ series digital multimeter has an innovative industrial design which ensures that the product can withstand a drop of 2 meters height. Large LCD screen provides a clear display and its 4 times/second sampling rate provides users with more accurate readings. UT136+ series is designed to work safely in CAT II1000V/CAT III 600V environment. This series is suitable for civil/commercial use such as HVAC technicians and electricians.



1. Measures up to 1000V and 10A AC/DC voltage and current
2. Equipped with 3mm protective sleeve; 2 meters drop proof
3. Large LCD display; Overload alarm
4. Quick sampling rate, up to 4 times/s
5. Quick capacitor measurement (measures 1mF in 4 seconds)
6. Low power consumption and auto power saving function; long battery service life (>500hrs)



Specifications Range UT136B+ UT136C+
DC voltage (V) 1000V ±(0.7%+3) ±(0.7%+3)
AC voltage (V) 1000V ±(1%+3) ±(1%+3)
DC current (A) 10A ±(1%+3) ±(1%+3)
AC current (A) 10A ±(1.2%+5) ±(1.2%+5)
Resistance (Ω) 40MΩ ±(0.8%+2) ±(0.8%+2)
Capacitance (F) 40mF ±(3%+5) ±(3%+5)
Frequency (Hz) 400Hz~40mHz ±(0.1%+4) ±(0.1%+4)
Temperature (°C) -40~1000° ±(1%+4)
Temperature (°) -40~1832° ±(1.5%+5)
Features
Display count 4000 4000
hFE Transistor measurement √ √
NCV Non-contact voltage detection √
Diode/transistor √ √
Continuity buzzer √ √
Data hold/Auto power off √ √
Low battery/Indication √ √
LCD backlight √ √
Safety rating CAT Ⅱ 1000V, CAT Ⅲ 600V √ √
Drop test 2m √ √
General Characteristics
Power 1.5V battery (R6) x 2(Battery not included)
Display 56.5mm x 36mm
Product net weight 330g
Product size 175mm x 83mm x 53mm
