Raspberry Pi 5 (4GB RAM)

Raspberry Pi 5 (4GB RAM)


In stock (can be backordered)

SKU: 0101 Categories: ,

Raspberry Pi 5 logo

Raspberry Pi 5 – 4G

Raspberry Pi 5 CPU

2 to 3 times higher performance

Featuring a 64-bit, quad-core Arm Cortex-A76 processor running at 2.4 GHz, the Raspberry Pi 5 represents a significant advance over its predecessor, the Raspberry Pi 4.

Indeed, this new iteration offers an impressive increase in processor performance, in the range of 2 to 3 times that of the Raspberry Pi 4.

In addition to improved graphics performance thanks to a VideoCore VII GPU clocked at 800 MHzdual 4Kp60 display output over micro HDMI and state-of-the-art camera support thanks to a re-architected Raspberry Pi image signal processor, it offers a smooth desktop experience for consumers and opens the way to new applications for industrial customers.

The new Raspberry Pi "RP1" Southbridge

I/O management via the new Raspberry Pi “RP1” Southbridge

For the first time, this is a full-size Raspberry Pi computer using silicon manufactured in-house by Raspberry Pi. The RP1 “southbridge” provides the bulk of the Raspberry Pi 5’s I/O capabilities and brings a radical change in peripheral performance and functionality.

Aggregate USB bandwidth is more than doubled, resulting in faster transfer speeds to external UAS drives and other high-speed peripherals.

The two-way 1Gbps MIPI camera and display interfaces found on previous models have been replaced by a pair of four-way 1.5 Gbps MIPI transceiverstripling total bandwidth and enabling up to two cameras or displays to be combined.

Maximum SD card performance is doubled, thanks to support for the SDR104 high-speed mode.

What’s more, this platform features a single-lane PCI Express 2.0 interface, providing bandwidth and information access for future accessories.

Raspberry Pi 5 Power Manager IC

New power management functions

The Raspberry Pi 5 features a brand-new power management integrated circuit (PMIC) specially designed for the Raspberry Pi, the DA9091 “Gilmour” PMIC.

This new circuit integrates new functionalities :

  • • Support for the new USB-PD PHY power supply standard
  • • RTC real-time clock with battery backup (optional)
  • • A dedicated power button on the edge of the board

Technical specifications


  • • 64-bit, quad-core Arm Cortex-A76 CPU running at 2.4 GHz, with
  • • 512 KB L2 cache and 2 MB shared L3 cache
  • • VideoCore VII GPU
  • • LPDDR4X-4267 SDRAM 4GB
  • • Wi-Fi 802.11ac at 2.4 GHz and 5.0 GHz
  • • Bluetooth 5.0 / Bluetooth Low Energy (BLE)
  • • Micro SD card slot, with support for high-speed SDR104 mode
  • • 2 × USB 3.0 ports, supporting simultaneous operation at 5 Gbps
  • • 2 × USB 2.0 ports
  • • Gigabit Ethernet, with PoE+ support (requires PoE+ HAT)
  • • 2 × 4-channel MIPI transceivers for cameras/displays
  • • PCIe 2.0 x1 interface for fast peripherals
  • • DC 5V/5A power supply (PD enabled)
  • • Raspberry Pi standard 40-pin header
  • • Real-time clock (RTC), powered by external battery
  • • Integrated power button
Raspberry Pi 5 board legend
Raspberry Pi 5 case with all parts
Acitive Cooler Raspberry Pi 5

Warnings Cooling system

For optimum use of your Raspberry Pi 5 board, be sure to use an efficient cooling system such as the one integrated in the new case or the Raspberry Pi active heatsink. Otherwise, CPU performance will be degraded in order to preserve processor integrity.

Raspberry Pi 4 – Pi 5 comparison

Raspberry Pi 4 Raspberry Pi 5
Architecture (bits) 64 64
SoC Broadcom BCM2711 Broadcom BCM2712
CPU 1.5GHz quad-core ARM Cortex-A72 2.4GHz quad-core ARM Cortex-A76
GPU VideoCore VI – 500 MHz
OpenGL ES 3.0
VideoCore VII – 800 MHz
OpenGL ES 3.1, Vulkan 1.2
RAM  1 Gb / 2 Gb / 4 Gb / 8 Gb 4 Gb / 8 Gb
Connectivity • 2.4 GHz and 5.0 GHz 802.11 ac wireless
• Bluetooth 5.0, BLE
• Gigabit Ethernet
• 2 USB 3.0 ports
(up to 5Gbps)
• 2 USB 2.0 ports
• Standard 40-pin GPIO
• 2 Micro HDMI ports (up to 4Kp60)
• 2-lane MIPI DSI, 2-lane MIPI CSI
• Stereo audio and composite video ports (4-pole)
• 2.4 GHz and 5.0 GHz wireless 802.11 ac
• Bluetooth 5.0, BLE
• Gigabit Ethernet
• 2 USB 3.0 ports
(5Gbps simultaneous)
• 2 USB 2.0 ports
• Standard 40-pin GPIO
• 2 Micro HDMI ports (up to 4Kp60)
• 2 x 4 MIPI lane

 PCIe 2.0 interface
Storage Micro-SD  Micro-SD
(high transfer speed – SDR104 mode)
RTC N/A RTC battery connector
Power supply 5V/ 3A
(via USB-C or GPIO connector)
5V/ 5A
(Power Delivery enabled)
PoE Via a separate PoE HAT Via separate PoE HAT
(new version)
Power on Instant after power-up ON/OFF button

Physical specifications


• Dimensions: 9.4 x 2.4 x 6.2 cm

• Weight: 46g

Raspberry Pi 5 - Physical dimensions
