150W inverter board 12VDC to 220VAC

150W inverter board 12VDC to 220VAC

6,500.00

In stock

SKU: 2329 Categories: ,

Features:
1.Quiescent current is 0.05A around.
2.Output waveform is frequency square wave.
3.Output frequency is 20KHz around.
4.PCB board using military grade plate, mainly used for electronic DIY before the inverter stage.
5.Adopt high quality PCB board, durable for use.

Descriptions:
1.Made of high quality material, it’s durable.

Specifications:
Product Name: 150W Inverter Boost Circuit Board
Material: Metal
Color: Multicolor
Power: 150W
Input: DC12V
Output: AC 110V-200V-220V (as photo shows). also can 110v-0-110v.
Quiescent Current: approx. 0.05A
Output Waveform: Frequency Square Wave
Output Frequency: 20KHz around
Protection: No Protection

The Default Output Voltage Wiring As Follows: Only for Reference
V0–V2=110V V0–V3=175V
V0–V4=200V V0–V5=220V
V5–V4=20V V5–V3=45V
V5–V2=110V V4–V3=28V
V4–V2=90V V3–V2=62V

Package Informations:
Package Size: 50x50x40mm/1.97×1.97×1.57in
Package Weight: 70g/2.47oz
General Package

Package Included:
1 x 150W Inverter Boost Circuit Board

Notes:
1.The board is a high frequency square wave ac output is generally inductive electrical tape can not “mortars, fen coil transformer etc.
2.Take a small load (led lights phone charger dvd set—top box, etc.) Connected to the output voltage of the recommendations, such as a low gear: 172v or 200v.
3.Load large work long hours (≥100w) is recommended to increase the heat sink.
4.Power can not be reversed. The other power supply and power cord should be large enough current. 5. Do not overload do not short circuit output. 6. Frequency output load voltage multimeter measurements will show higher (is not correct,not actual voltage).
